MoTeC

MoTeC C125 / C127 / C1212 Enable 17 I/O

SKU: MOT-M-C12X-I-O
(0)
In stock

Item is ready to ship

Usually ships within 24 hours
$400.00

Buying the ECU at the same time? Just confirm the model.

On the ECU label, or in MoTeC software under Help > About. Leave blank if the ECU is on this order - we will pair them for you.

Got questions?
Feel free to get in touch

Ask an expert

Video chat Chat Email

What the stock status means

In stock — Item is ready to ship
Backorder — Item is normally stocked, but zero on hand
Special Order — Item is made to order and/or not normally stocked

*Ensure your serial number is accurate. This code is not refundable and cannot be moved to a different serial number after ordering.

Inputs:

  • 2 x Digital and 3 x Speed inputs
  • 1 x Composite video input

Inputs - optional (requires 1/0 upgrade)

  • 6 x Analogue voltage inputs:

- 4 x 0 to 5.46 V, 1.33 mV resolution

- 2 x 0 to 15.0 V, 3.66 mV resolution

  • 2 x Analogue temperature inputs:

- 0 to 15 V, 3.66 mV resolution

Outputs- optional (requires 1/0 upgrade)

  • 4 x low side outputs PWM or switched operation
  • 0.5 Amp max, current limited, thermal overload protected

MoTeC part number: M C12X I/O
