The ICON Vehicle Dynamics Stage 2 6" Suspension System is engineered to transform the 2022-2026 Toyota Tundra into a highly capable on- and off-road performer while providing the clearance to run 37-inch tires at full articulation. Vehicle-specific tuned 2.5 Series front coilovers with internal reservoirs deliver exceptional damping performance, improved vehicle control, and up to a 40% increase in front wheel travel over stock without overstressing OE suspension components. Adjustable ride height provides 5-6 inches of front lift, while the system's innovative design achieves a full 6 inches of lift with only 4 inches of crossmember drop to maximize ground clearance and minimize CV joint angles. Tubular upper control arms equipped with ICON's patented Delta Joint Pro (U.S. Pat. 10,731,700) provide increased strength, exceptional durability, improved caster correction for enhanced drivability, and 90 degrees of total articulation for unrestricted suspension movement. The system maintains factory track width while optimized suspension geometry nearly eliminates the bump steer characteristic of stock Tundras.
This Part Fits:
| Year | Make | Model | Submodel |
|---|---|---|---|
| 2022-2026 | Toyota | Tundra | 1794 Edition |
| 2022-2026 | Toyota | Tundra | Limited |
| 2022-2026 | Toyota | Tundra | Platinum |
| 2022-2026 | Toyota | Tundra | SR |
| 2022-2026 | Toyota | Tundra | SR5 |
| 2022-2026 | Toyota | Tundra | TRD Pro |
